Smart Bio NexusUHF1-Tag4 · eSSL
eSSL · RFID cards & tags
UHF1-Tag4
Explore eSSL wristbands and UHF tags.
- Working Frequency : 860~960MHz
- Working Mode : Passive (no battery)
- Data Storage Period : 10 Years
- Working Temperature : 0~60℃
Authorised eSSL channel partner · Chennai
Ask us about configuration, installation and service.
Product highlights
A closer look at the features.
Smart Bio NexusWorking Frequency : 860~960MHz
Working Mode : Passive (no battery)
Data Storage Period : 10 Years
Working Temperature : 0~60℃
Chip : Alien H3
Manufacturer details
Published product details.
Feature
| Anti-tear | when torn, it will be destroyed |
|---|
- High Safety
- Long Service Life
- High Reading Rate
- High Chip Sensitivity
- Flexible Storage Structure
- Reading and Writing Repeatedly
- Adhesive Design, Easy Installation
Technical Specifications
| Working Frequency | 860MHz~960MHz |
|---|---|
| Reading Distance | Up to 10 meters for UHF1-10E and UHF1-10F (Determined by the environment and reader) Protocol Standard : ISO/IEC 18000-6C, EPC global Class 1 Gen 2 |
| Chip | Alien H3 |
| Working Mode | Passive (no battery) |
| Storage Structure | EPC: 96bits, UID/TID: 64bits, User: 512bits Kill Password: 32bits, Access Password: 32bits |
| Erase Endurance | 100,000 Times |
| Data Storage Period | 10 Years |
| Working Temperature | 0~60℃ |
| Storage Humidity | 20%~60% RH |
| Immunity Against Electrostatic Voltage | 2 KV (HBM) |
| Curvature | > 60mm |
| Dimension | 96.5x23.2 (mm) ±0.5(mm) |
| Installation | Stick on the windshield ( Parking Applications ) |
Typical Applications
- Goods Management
- Vehicle Management
- Highway (Bridge) Toll Collection Management
